Knock Sensor Replacement Engine Control Engine Control Sensors Knock Sensor

Knock Sensor Replacement

Callout

Component Name

Preliminary Procedure

Remove the starter. Refer toStarter Replacement

1

Knock Sensor Fastener

Caution:Refer toFastener Caution.

Tighten

25-Y (18-lb-ft)

2

Knock Sensor

Procedure

Disconnect the electrical connector.
