Front View Camera Replacement

Callout

Component Name

Preliminary Procedure

Remove the inside rearview mirror mount plate cover. Refer toInside Rearview Mirror Mount Plate Cover Replacement.

Front View Camera

ProcedureDisconnect the electrical connector.Pull on the upper tab of the camera bracket upward.While holding the camera, slide the two bottom tabs out.After replacement of the front view camera, program the front view camera. Refer toControl Module References.
