Evaporative Emission Line Replacement - Canister to Tank Engine Control

Evaporative Emission Line Replacement - Canister to Tank

Callout

Component Name

Preliminary ProcedureRemove the fuel tank. Refer toFuel Tank Replacement.Disconnect the plastic quick connects. Refer toPlastic Collar Quick Connect Fitting Service.

Evaporative Emission Line Canister to Tank

Procedure

Disconnect the electrical connector.
