Chevrolet Equinox Service Manual: Drive Sprocket, Driven Sprocket, and Drive Link Cleaning and Inspection Automatic Transmission Unit

Chevrolet Equinox Service Manual / Powertrain / Transmission/Transaxle / Drive Sprocket, Driven Sprocket, and Drive Link Cleaning and Inspection Automatic Transmission Unit

Drive Sprocket, Driven Sprocket, and Drive Link Cleaning and Inspection Automatic Transmission Unit

Drive Sprocket, Driven Sprocket, and Drive Link Cleaning and Inspection

Callout

Component Name

1

Drive Sprocket Thrust Washer

2

Drive Sprocket Retainer Ring

3

Drive Sprocket

4

Drive Sprocket Bearing Assembly

5

Park Gear

6

Driven Sprocket

7

Drive Link Assembly

Drive and Driven Sprocket, Drive Link, and Park Pawl Removal (6T40/45/50) Automatic Transmission Unit
Drive and Driven Sprocket, Drive Link, and Park Pawl RemovalCalloutComponent Name1Drive Link Lube Scoop2Drive Link Lube Scoop Seals3Drive Link Lube Fluid Seal4Driven Sprocket Assembly, Drive Sprocket ...
