Roof Panel Molding Replacement (Equinox without V59) Panels Roof Panel

Roof Panel Molding Replacement

Callout

Component Name

Preliminary Procedure

Remove the luggage carrier side rail. Refer toLuggage Carrier Side Rail Replacement.

1

Roof Panel Molding Assembly

Procedure

Lift the molding from the metal retainer clips in the roofditch.
